Hoover U4203 - Concept One Upright Vacuum
1. Spring 38334002
2. Outer Zipper Vinyl Bag Common White Checked Part No Longer Available
3. Top Fill Tube Part No Longer Available
4. Type A Paper Bag (3 pack) 4010001
4. Type A Paper Bag (10 pack) 4010324
4. Type A Paper Bag Micro Filter (3 pack) 4010100
5. Jacket Bottom 36425001
6. Hoover Screw 21447215
7. Screw Part No Longer Available
8. Motor Cover Beige 37195008
9. Screw 21447013
10. Motor (1 speed) Part No Longer Available
10. Motor (2 speed) 43576038
11. Mount Ring 32155006
12. Seal Ring 32156007
13. Motor Mount (Fan End) 32175011
14. Lamp Socket Assembly 47176001
15. Screw 21447003
16. Dirt Finder Lamp 27313101
17. Nut For Pivot Bearing Part No Longer Available
18. Motor Mount 32162003
19. Pivot Bearing (Front Housing) 38511002
20. Terminals 12227
21. Actuator Bar Assy With Screws 43143075
22. Pivot Bearing U3103 U3109 Part No Longer Available
23. Nut 160061
24. Bolt Part No Longer Available
25. Lens & Shield Assembly 48111002
26. Brush Block Insulator Part No Longer Available
27. Cord Reel Complete 46831106
28. Control Cable Tube Part No Longer Available
29. Brush Block Assembly 47348045
30. Handle Tube Assembly U3101 Part No Longer Available
31. Lead Wire Assembly 46514001 Part No Longer Available
31. Lead Wire Assembly U3109 U3109-100 U3223-9 Part No Longer Available
32. Tension Spring 38333006
33. Cord Reel Brake Pad 34121007
34. Screw Part No Longer Available
35. Screw 21447020
36. Jacket Support Part No Longer Available
37. Hoover Cord Power U5163 Fold Away 46383348
39. Motor Tape (5/8" x 180') Part No Longer Available
40. Control Cable 42-1/8" (Old Style) Part No Longer Available

1. Hood 3303 4213 Part No Longer Available
2. Cam 38563006
3. Air Duct 38656023
4. Screw 21447014
5. Duct Seal 34123003
6. Screw Assembly Part No Longer Available
7. Foot Pad U3101 38426030
8. Handle Release Lever (Right) 3101 38452059
9. Lock Ring (for Rear Wheel) Part No Longer Available
10. Rear Wheel U3101 38522017
11. Pivot Bearing (Agitator Housing) 32155004
12. Frame Assembly (Right) Part No Longer Available
13. Rear Axle 32547002
14. Frame (Left) 35476011
15. Bottom Duct Seal Part No Longer Available
16. Bottom Plate All Models Part No Longer Available
17. Agitator Pulley Seal 38781006
18. Handle Release Lever (Left) Part No Longer Available
19. Spring 161513
19. Spring (Handle Release) U4201 38335014
20. Screw Assembly Part No Longer Available
21. Belt Power Drive 160147
22. Power Drive Unit 43124006
23. Seal 12173
24. Agitator Housing Assembly Part No Longer Available
25. Agitator Clip Part No Longer Available
26. Agitator Clip Pin 31522016
27. Agitator Housing Bracket (Right) 35476005
28. Screw 21447003
29. Furniture Guard U3103 (Gray) Part No Longer Available
30. Name Plate U3103 Part No Longer Available
30. Name Plate 3101 Part No Longer Available
31. Drive Pulley 38537001
32. Front Axle 4201 4203 4211 4213 32543005
33. Wheel Carriage (Left) 4201 4203 4211 4213 35476007
34. Wheel Carriage (Right) 4201 4203 4211 4213 41431014
35. Roller Part No Longer Available
36. Retainer Ring Part No Longer Available
37. Front Wheel 4201 4203 4211 4213 Part No Longer Available
38. Hoover Lever Handle Control U6311 38452053
39. Detent Spring U3101 U4203 34751002
40. Wheel Cover U3103 4203 Part No Longer Available
41. Nozzle Adjustment Level Part No Longer Available
Sort By:
1
Agitator Housing Bracket (Right) Agitator Pulley Seal
Our Price: $2.77
more info
Our Price: $3.25
more info This item is No Longer Available
Agitator Housing Bracket (Right) Agitator Pulley Seal
Agitator Housing Bracket (Right) Agitator Pulley Seal
Air Duct C1800 TOP FILL PAPER BAG - 3 PACK
Our Price: $5.02
Sale Price: $4.49
You save $0.53!
more info
Our Price: $3.89
Sale Price: $3.49
You save $0.40!
more info
Air Duct C1800 TOP FILL PAPER BAG - 3 PACK
Air Duct C1800 TOP FILL PAPER BAG - 3 PACK
Cam CLOTH BAG, CONCEPT II/ POWER MAX BEIGE
Our Price: $1.99
more info
Our Price: $26.99
more info
Cam CLOTH BAG, CONCEPT II/ POWER MAX BEIGE
Cam CLOTH BAG, CONCEPT II/ POWER MAX BEIGE.  Genuine Hoover Vacuum Part.
Connector (2) Frame (Left)
Our Price: $0.89
more info
Our Price: $3.25
more info
Connector (2) Frame (Left)
Connector (2) Frame (Left)
Furniture Nozzle With Litter Picker 43414057 Hoover "A" Allergen Filter Bags Pkg of 3 4010100A
List Price: $10.99
Our Price: $9.75
Sale Price: $8.25
You save $2.74!
more info
List Price: $9.50
Our Price: $8.99
Sale Price: $7.95
You save $1.55!
more info
Hoover Furniture Nozzle with litter picker 43414057 Hoover Vacuum Type "A" Allergen Filter Bags
Furniture Nozzle with litter picker sub 40-1705-08 Genuine Hoover Vacuum Bag. Hoover Vacuum Type "A" Allergen Filter Bags Package of 3

Alternative Hoover Type "A" Bags:
Allergen Filter Bags (Package of 3)
Standard Bags (Package of 3)
Filter Bags (Package of 10)
HEPA Bags (Package of 2)
Cloth Reusable Bag
Hoover "A" Filter Bags Pkg 10 PAK THIS ITEM IS NO LONGER AVAILABLE Hoover "A" Standard Bags Pkg of 3 4010001A
List Price: $14.27
Our Price: $13.99
Sale Price: $12.95
You save $1.32!
more info
List Price: $6.99
Our Price: $5.49
Sale Price: $5.25
You save $1.74!
more info
Hoover Vacuum Type "A" Filter Bags Hoover "A" Standard Bag Pkg of 3
Genuine Hoover Vacuum Bag.  Hoover Vacuum Type "A" Filter Bags Package of 10 Genuine Hoover Vacuum Bag.  Hoover Vacuum Type "A" Standard Bags Package of 3,
Hoover Agitator Bearing 43267002 Hoover Armature Concept 1 And 2
List Price: $6.49
Our Price: $5.99
Sale Price: $5.25
You save $1.24!
more info
Our Price: $58.70
more info
Hoover Agitator Bearing 43267002 Hoover Armature Concept 1 And 2
Hoover Agitator Bearing.  Genuine Hoover Vacuum Part. 43267002 Hoover Armature Concept 1 And 2
Hoover Axle Front U3301 U7069 Conquest Hoover Axle Rear U3101 U3103
Our Price: $3.62
Sale Price: $2.99
You save $0.63!
more info
Our Price: $20.40
Sale Price: $16.99
You save $3.41!
more info
Hoover Axle Front U3301 U7069 Conquest Hoover Axle Rear U3101 U3103
Hoover Axle Front U3301 U7069 Conquest .  Genuine Hoover Vacuum Part. Hoover Axle Rear U3101 U3103 .  Genuine Hoover Vacuum Part.
Hoover Bottom Plate Self Tapping Screw | 21447215 Hoover C1800 Handle Grip Assembly | 39454060
List Price: $2.25
Our Price: $2.10
Sale Price: $1.95
You save $0.30!
more info This item is No Longer Available
List Price: $24.50
Our Price: $22.00
Sale Price: $19.99
You save $4.51!
more info
Hoover Bottom Plate Self Tapping Screw | 21447215 Hoover C1800 Handle Grip Assembly 39454060,H-48663072
Hoover Bottom Plate Self Tapping Screw | 21447215 Hoover C1800 Handle Grip Assembly  39454060,H-48663072
Hoover Cam U6311 Hoover Carbon Brush 47315010
Our Price: $3.11
Sale Price: $2.99
You save $0.12!
more info
List Price: $8.99
Our Price: $7.75
Sale Price: $6.25
You save $2.74!
more info
Hoover Cam U6311 Hoover Carbon Brush 47315010
Hoover Cam U6311 .  Genuine Hoover Vacuum Part. Hoover Carbon Brush .  Genuine Hoover Vacuum Part. 47315010
Hoover Collar Hose Connector HOOVER COMMUTATOR BLOCK-COR
Our Price: $1.17
more info
Our Price: $5.02
more info
Hoover Collar Hose Connector HOOVER COMMUTATOR BLOCK-COR
Hoover Collar Hose Connector HOOVER COMMUTATOR BLOCK-COR
Hoover Concept Flat Brushroller Belt | 38528008* HOOVER CONCEPT/SPIRIT/CELEBRITY III-IV CORD REEL
List Price: $6.99
Our Price: $5.95
Sale Price: $4.75
You save $2.24!
more info
Our Price: $59.54
Sale Price: $54.95
You save $4.59!
more info
Hoover Belt 38528008 Cord Reel Complete
Hoover Belt for Concept Agitator. This Hoover agitator belt is for Concept one, Concept two, Self-Propelled PowerMax, Power Drive and Dirt Finder upright vacuum models.H-38528008,38528008 Size is 4-3/8" outer diameter. HOOVER CONCEPT/SPIRIT/CELEBRITY III-IV CORD REEL
Hoover Converter Concept Gray Hoover Dusting Brush | 43414064
Our Price: $10.56
more info
List Price: $10.99
Our Price: $9.99
Sale Price: $8.75
You save $2.24!
more info
Hoover Converter Concept Gray Hoover Dusting Brush | 43414064
Hoover Converter Concept Gray Hoover Vacuum Cleaner Dusting Brush with lock pin. Fits on all Hoover canisters which have attachments that fit inside the wands. It has a pin on the top of the connector to lock it into place. This dusting brush is square and measures 2 7/8 inches wide. Genuine Hoover vacuum part.43414064,H-43414064
Hoover Field 1 Speed Concept 3101 Hoover Field 2 Speed Concept I U3225
Our Price: $28.93
more info
Our Price: $32.21
more info
Hoover Field 1 Speed Concept 3101 Hoover Field 2 Speed Concept I U3225
Hoover Field 1 Speed Concept 3101 Hoover Field 2 Speed Concept I U3225
Hoover Floor Brush With Swivel Neck | Gray 440009293 Hoover Front Housing Assembly U4203
List Price: $18.99
Our Price: $16.00
Sale Price: $14.25
You save $4.74!
more info
Our Price: $17.55
more info
Hoover Floor Brush Black 43414073,440009293,H-43414073 Hoover Front Housing Assembly U4203
Black Hoover canister vacuum cleaner floor brush fits on all Hoover canisters which have attachments that fit inside the wands. It has a pin on the top of the connector to lock it into place. This floor brush has a swivel neck and is 9 inches wide and 2 inches deep, with three nylon brush strips. Comes standard with most Hoover canister vacuums. Genuine Hoover vacuum cleaner attachment.
Hoover Front Housing Assembly U4203
Hoover Handle Release Lever Hoover Hose Sleeve Insert
Our Price: $4.86
Sale Price: $3.99
You save $0.87!
more info
Our Price: $1.17
more info
Hoover Handle Release Lever Hoover Hose Sleeve Insert
Hoover Handle Release Lever.  Genuine Hoover Vacuum Part. Hoover Hose Sleeve Insert
THIS ITEM IS NO LONGER AVAILABLE
Hoover Housing Motor With Bearing Concept Power Max 3101 3103 Hoover Lever Handle Control U6311
Our Price: $16.43
more info
Our Price: $1.50
more info
Hoover Housing Motor With Bearing Concept Power Max 3101 3103 Hoover Lever Handle Control U6311
Hoover Housing Motor With Bearing Concept Power Max 3101 3103 Hoover Lever Handle Control U6311
Hoover Lever Handle Control U6311 Right Hand HOOVER NLA HOOD
Our Price: $3.09
Sale Price: $2.79
You save $0.30!
more info
Our Price: $15.28
more info
Hoover Lever Handle Control U6311 Right Hand HOOVER NLA HOOD
Hoover Lever Handle Control U6311 Right Hand .  Genuine Hoover Vacuum Part. HOOVER NLA HOOD
Hoover Nozzle Adjustment Lever & Cam (E) Hoover Pad Switch 12 pack
Our Price: $3.99
Sale Price: $2.99
You save $1.00!
more info
Our Price: $2.99
more info
40309004 Hoover Pad Switch 12 pack
Hoover Nozzle Adjustment Lever & Cam Hoover Pad Switch 12 pack
Hoover Pin Clip Agitator Housing U6311 Hoover Pivot Bearing Agitator U3101
Our Price: $1.19
more info
Our Price: $1.44
more info
Hoover Pin Clip Agitator Housing U6311 Hoover Pivot Bearing Agitator U3101
Hoover Pin Clip Agitator Housing U6311 .  Genuine Hoover Vacuum Part.
THIS ITEM IS NO LONGER AVAILABLE 		Hoover Pivot Bearing Agitator U3101 .  Genuine Hoover Vacuum Part.
Hoover Power Drive Belt | 160147AG Hoover Pulley Power Drive Concept Black Plastic U3101
List Price: $4.99
Our Price: $3.75
Sale Price: $3.45
You save $1.54!
more info
List Price: $6.99
Our Price: $6.10
Sale Price: $5.25
You save $1.74!
more info
Hoover Power Drive Belt 160147AG Hoover Pulley Power Drive Concept Black Plastic U3101
HOOVER POWER DRIVE BELT FOR POWER DRIVE MODELS U6311, U6317, U6318, U6323, U6329, AUTO DRIVE MODEL 6319, TURBOPOWER 6000 MODEL 6321, Hoover Pulley Power Drive Concept Black Plastic U3101.  Genuine Hoover Vacuum Part.
Hoover Screw Carbon Brush Holder C7069 C7071 12PK Hoover Screw Holds Motor To Base Uprt Extractors
Our Price: $0.89
more info
Our Price: $1.95
more info
Hoover Screw Carbon Brush Holder C7069 C7071 12PK Hoover Screw Holds Motor To Base Uprt Extractors
Hoover Screw Carbon Brush Holder C7069 C7071 12PK .  Genuine Hoover Vacuum Part. Hoover Screw Holds Motor To Base Uprt Extractors
Hoover Slide On Terminal 27666702 HOOVER SPLIT RING
List Price: $3.99
Our Price: $3.49
Sale Price: $2.99
You save $1.00!
more info This item is No Longer Available
Our Price: $1.50
more info
Hoover Slide On Terminal 27666702 HOOVER SPLIT RING
Hoover Slide On Terminal  27666702 HOOVER SPLIT RING
Hoover Spring Carbon Brush Constellation U3101 U3103 U4201 U4203 Hoover Spring Detent U3101
Our Price: $1.35
more info
Our Price: $0.79
more info
Hoover Spring Carbon Brush Constellation U3101 U3103 U4201 U4203 Hoover Spring Detent U3101
Hoover Spring Carbon Brush Constellation U3101 U3103 U4201 U4203.  Genuine Hoover Vacuum Part. Hoover Spring Detent U3101 .  Genuine Hoover Vacuum Part.
Hoover Spring Handle Release Hoover Spring Rear Wheel Height Adjustment
Our Price: $1.19
more info
Our Price: $1.49
more info
Hoover Spring Handle Release Hoover Spring Rear Wheel Height Adjustment
Hoover Spring Handle Release.  Genuine Hoover Vacuum Part. Hoover Spring Rear Wheel Height Adjustment
Hoover Sprint Crevice Tool | 38617017 Hoover Switch Button
List Price: $6.99
Our Price: $6.10
Sale Price: $5.75
You save $1.24!
more info
Our Price: $2.23
Sale Price: $1.49
You save $0.74!
more info
Hoover Crevice tool made for Hoover twist lock system wands. 38617017,H-38617017+ USA VACUUM Hoover Switch Button
8.5" Black Crevice Tool with Locking Pin 8 1/2" black crevice tool fits on Hoover canisters which use attachments with a pin on the connector which fits INSIDE the hoses or wands. It is not for use on Hoover uprights nor Hoover Bagless canisters since their attachments fit OVER the wands. Model #: 38617017 See prt. # 38617023 for crevice tool that fits Hoover uprights.
Hoover Switch Button .  Genuine Hoover Vacuum Part.
Hoover Terminal Hoover Thread Guard Agitator U3101 U4201
Our Price: $1.99
more info This item is No Longer Available
Our Price: $3.10
Sale Price: $2.60
You save $0.50!
more info
Hoover Terminal Hoover Thread Guard Agitator U3101 U4201
Replacement Hoover Terminal Hoover Thread Guard Agitator U3101 U4201 .  Genuine Hoover Vacuum Part.
Hoover Thrust Washer 21347003 Hoover Vacuum Cleaner Light Bulb | 27313101
List Price: $2.99
Our Price: $2.49
Sale Price: $1.99
You save $1.00!
more info This item is No Longer Available
List Price: $5.00
Our Price: $4.50
Sale Price: $3.75
You save $1.25!
more info
Hoover Thrust Washer Hoover Vacuum Cleaner Light Bulb | 27313101
Hoover Thrust Washer .  Genuine Hoover Vacuum Part. Hoover Vacuum Cleaner Light Bulb | 27313101,H-27313101
HOOVER WBD HOSE GRIP W/SC-AG-S1 HOOVER WBD SUCTION CONTROL RING
Our Price: $7.99
more info
Our Price: $1.19
more info
HOOVER WBD HOSE GRIP W/SC-AG-S1 HOOVER WBD SUCTION CONTROL RING
HOOVER WBD HOSE GRIP W/SC-AG-S1 HOOVER WBD SUCTION CONTROL RING
Jacket Bottom Lamp Socket Assembly
Our Price: $2.51
more info
Our Price: $2.34
more info
Jacket Bottom Lamp Socket Assembly
Jacket Bottom Lamp Socket Assembly
Lead Wire Tie Lens & Shield Assembly
Our Price: $0.79
more info
Our Price: $4.10
more info
Lead Wire Tie Lens & Shield Assembly
Lead Wire Tie Lens & Shield Assembly
Motor Cover Beige Motor Mount
Our Price: $9.74
Sale Price: $8.99
You save $0.75!
more info
Our Price: $3.50
more info
Motor Cover Beige Motor Mount
Motor Cover Beige Motor Mount
Motor Mount (Fan End) Mount Ring
Our Price: $1.99
more info
Our Price: $0.79
more info
Motor Mount (Fan End) Mount Ring
Motor Mount (Fan End) Mount Ring
Nut ORIGINAL HOOVER BEARING
Our Price: $0.89
more info
Our Price: $2.67
Sale Price: $2.29
You save $0.38!
more info
Nut ORIGINAL HOOVER BEARING FOR POWER DRIVE MODELS U6311, U6317, U6318, U6323, U6329, AUTO DRIVE MODEL 6319, TURBOPOWER 6000 MODEL 6321
Nut ORIGINAL HOOVER BEARING FOR POWER DRIVE MODELS U6311, U6317, U6318, U6323, U6329, AUTO DRIVE MODEL 6319, TURBOPOWER 6000 MODEL 6321
ORIGINAL HOOVER SCREW (SELF-TAPPING) Screw
Our Price: $0.89
more info This item is No Longer Available
Our Price: $0.89
more info
ORIGINAL HOOVER SCREW (SELF-TAPPING) FOR POWER DRIVE MODELS U6311, U6317, U6318, U6323, U6329, AUTO DRIVE MODEL 6319, TURBOPOWER 6000 MODEL 6321 Screw
ORIGINAL HOOVER SCREW (SELF-TAPPING) FOR POWER DRIVE MODELS U6311, U6317, U6318, U6323, U6329, AUTO DRIVE MODEL 6319, TURBOPOWER 6000 MODEL 6321 Screw
Screw Seal
Our Price: $0.69
more info
Our Price: $2.25
more info
Screw Seal
Screw Seal
Seal Ring Tension Spring
Our Price: $1.50
more info
Our Price: $0.89
more info
Seal Ring Tension Spring
Seal Ring Tension Spring
Wheel Carriage (Left) 4201 4203 4211 4213 Wheel Carriage (Right) 4201 4203 4211 4213
Our Price: $3.25
more info
Our Price: $8.02
Sale Price: $7.29
You save $0.73!
more info
Wheel Carriage (Left) 4201 4203 4211 4213 Wheel Carriage (Right) 4201 4203 4211 4213
Wheel Carriage (Left) 4201 4203 4211 4213 Wheel Carriage (Right) 4201 4203 4211 4213


1
Talk
STAY CONNECTED

Truck
FREE SHIPPING AVAILABLE
All orders over $75 receive free shipping see details >>
