Kirby Generation V (G5)

Kirby Generation V (G5)
Kirby Generation V (G5) Attachments

Kirby Generation V (G5) Attachments
Item Part Number
1. Kirby Inflator Tool G6/UG 213801
2. Kirby Carry Handle Assembly G6 Black 201399
3. Attachment Grip 225197
4. Kirby Massage Cup Black 505/LGI/G6 214199
5. Intake Guard Assembly Part No Longer Available
6. Kaddy Assembly Part No Longer Available
7. Kirby Spray Gun Assembly G3 G4 G5 G6 Ultimate 250299S
8. Supply Tube Spray Gun 250689S
9. Jar Spray Gun 251089
10. Crevice Tool Assembly 225797S
11. Brush Crevice Tool 226157S 5
12. Upholstery Tool 218097
13. Extension Wand 224097
14. Kirby Spray Gun Suds-O-Cap G6 252099S
15. Wall Ceiling Brush Assembly 210897S
16. Brush Strip Wall Ceiling 218190
17. Surface Nozzle Assembly 215497
18. Duster Brush Assembly 218497S
19. Duster Brush Ring 220189
20. Attachment Hose Assembly 223697S
21. Molded Hose Only 223006
22. Tube Swivel Connector 223397
23. Suction Blower Connector 210097
24. Wheel Axle Assembly Surface Nozzle 216897S 2
25. Polymer Plate Surface Nozzle 216391
26. Bush Strip Surface Nozzle Part No Longer Available
27. Kirby Suction Relief Upholstery Tool G6 215899
28. Trigger Spray Gun Part No Longer Available
29. Venturi Spray Gun Part No Longer Available
30. Kaddy Assembly Strap Part No Longer Available
31. Kaddy Strap Push Nut Part No Longer Available
32. Cover Portable Handle Part No Longer Available
33. G5 Attachment Set 207097S
Kirby Generation V (G5) Base Pan Assembly

Kirby Generation V (G5) Base Pan Assembly
Item Part Number
2. O Ring Horn Adapter 601996S
3. Rivet Horn Adapter 100689A
4. Exhaust Duct 106393
5. Grill Exhaust Duct 104197S 5
6. Screw (Torx) Exhaust Duct 605989A
7. 31' Cord Set With Clip (120 VT) 192097
8. Kirby Cover For Cord Set G6 196099
9. Screw (Torx) Cord Cover 232495S
Kirby Generation V (G5) Cloth Bag & Mini Emtor Assembly

Kirby Generation V (G5) Cloth Bag & Mini Emtor Assembly
Item Part Number
1. Bag Mini Em Tor Assembly 187997G
2. Bag Assembly (With Latch Only) 190097
3. Bag Top Cover 191897
4. Kirby Latch Bag Top G4-G6 Black 196499S
5. Kirby Strap Bag Clamp G3, G4, G5, G6 196599S
6. Fill Tube Mini Em Tor Assembly 185899S
7. Paper Bag (9 pack) 197394AW
8. Paper Bag (3 pack) 197294SW
Kirby Generation V (G5) Cover Shell Assembly

Kirby Generation V (G5) Cover Shell Assembly
Item Part Number
1. Cover Less Trim Strips Part No Longer Available
2. Left Trim Strip Cover 630997S
3. Right Trim Strip Cover 630897S
4. Scuff Plate 120 VT 111297
5. Screw (Torx) Scuff Plate Rear 233405S
6. Kirby Screw Front Cover G3/UG (10pk) 232395S
7. Screw (Torx) Cover to Base Pan Rear 232495S
8. Screw (Torx) Cord Clip 233596S
Kirby Generation V5 (G5) Fan Case Assembly

Kirby Generation V5 (G5) Fan Case Assembly
Item Part Number
1. Fan Case Assembly 119797S
2. Screw Nozzle Lock 1211S
3. Spring Nozzle Lock 121297S 10
4. Lever Nozzle Lock 125297A 2
5. Kirby Bezel For Power Switch G4 G5 G6 610099S
6. Nozzle Attaching Shaft 121689S
7. Unigasket Fan Case 122097S
8. Wheel Shaft Assembly (Inside Shaft Length 8 7/16") 131606S
9. Ratchet Lock 631589A
10. Screw (Torx) Front Shaft Clamp 231294A
10. Screw (Torx) Front Shaft Clamp 231294A
11. Clamp Front Shaft 134073A
11. Clamp Front Shaft 134073A
12. Hubcap Front Wheel 131897A
12. Hubcap Front Wheel 131897A
13. Kirby Wheel Front G6 131999
13. Kirby Wheel Front G6 131999
14. Screw (Torx) Front Wheel 231695A
14. Screw (Torx) Front Wheel 231695A
15. Spring Ratchet Lock 1331A
16. Volute Deflector 125489
17. Screw (Torx) Fan Case Slide Bracket (Top) 231595S
17. Screw (Torx) Fan Case Slide Bracket (Top) 231595S
18. Screw (Torx) Fan Case Base Pan (Bottom) 234898S 10
18. Screw (Torx) Fan Case Base Pan (Bottom) 234898S 10
19. Screw (Torx) Fan Case Base Pan Flat Head 234998S 10
Kirby Generation V (G5) Floor Nozzle Assembly

Kirby Generation V (G5) Floor Nozzle Assembly
Item Part Number
1. Nozzle Assembly (Less Brush and Belt) 141697S
2. Label Belt Lifter 673697S 5
3. Screw (Torx) Belt Lifter 232596S
4. Belt Lifter Body Assembly 159297S
5. Flat Washer Belt Lifter 144681A
6. Spring Washer Belt Lifter 314890S 10
7. Kirby Label For Belt Lifter UG (5pk) 146606S
8. Label Brush Adjustment 149801S
9. Bearing Belt Lifter 145481S 10
10. Hook Belt Lifter 144291
11. Rug Plate Latch Assembly 640689A 2
12. Rivet Latch Assembly 141381S 10
13. Nozzle Bumper 140497
14. Rug Plate 152604
15. Kirby Brushroll W/Magnet G5-DE Stiff Bristles 152505G
15. Kirby Brushroll W/Magnet G5-DE Stiff Bristles 152505G
16. Brush End Cap Small Part No Longer Available
17. Brush End Cap Large Part No Longer Available
18. Belt Knurled Brush Roll 301291S
19. Sleeve Rug Plate Latch 640589s 10
Kirby Generation V (G5) Handle Fork & Grip Assembly

Kirby Generation V (G5) Handle Fork & Grip Assembly
Item Part Number
1. Handle Fork Assembly 175097G
2. Latch Plate 672189
3. Kirby Screw For Handle Fork Plate G3-UG 233797S
4. Label Handle Fork 174397S 5
5. Strain Relief Rear Cover 175097G
6. Retainer Ring Strain Relief 675189S
7. Metal Screw Bank Retainer 174996S
8. Cord Hook Swivel 173897S 5
9. Screw Cord Hook Swivel 174091A
10. Spring Cord Hook Swivel 174167A
11. Handle Grip Assembly 675797
12. Rear Cover Assembly 673797S
13. Bag Release Button Handle Grip 672097S 5
Kirby Generation V (G5) Headlight Cap/Slide Bracket/Handle Pivot Spring Assembly

Kirby Generation V (G5) Headlight Cap / Slide Bracket / Handle Pivot Spring Assembly
Item Part Number
1. Headlight Cap Casting 160097
2. Lens Headlight Cap 108597
3. Lightbulb 109292S
4. Headlight Frame Bracket 161797
5. Screw (Torx) Headlight Pivot to Slide Bracket 232495S
5. Screw (Torx) Headlight Pivot to Slide Bracket 232495S
6. Headlight Pivot Casting 161389
7. Bushing Headlight Pivot 161689S 5
8. Plate Headlight Pivot 162889S 5
9. Screw (Torx) Plate to Headlight Pivot 102168S 25
10. Slide Bracket Casting 894003S
11. Wedge Slide Adjustment 179489S
12. Guide Block Slide Bracket 178797S
13. Screw Guide and Wedge to Slide Bracket 234397S 10
13. Screw Guide and Wedge to Slide Bracket 234397S 10
13. Screw Guide and Wedge to Slide Bracket 234397S 10
14. Roller Bearing Assembly 178989S 10
15. Slide with Centering Spring Assembly 676595S
16. Tube Insulation Right Leg of Slide Bracket Casting 611192S 5
17. Headlight Harness Assembly 120 VT 603889S
18. Insulator Sleeve Black 660589S 5
19. Insulator Sleeve Clear 606889S 5
20. Headlight Jumper Wire 607189A
21. Cable Tie Headlight Lead Wires 608089S 10
22. Kirby Handle Pivot Spring W/Boot Sentria 671906G
23. Tilt Latch Knob Part No Longer Available
24. Kirby Boot Handle Pivot Spring G4/G6 178699S
25. Kirby Screw Handle Pivot To Slide Torx G3-UG(10pk) 233897S
26. Screw (Torx) Slide Bracket Casting (Rear) 232495S
26. Screw (Torx) Slide Bracket Casting (Rear) 232495S
27. Cable Tie Insualtion Tube Slide Bracket 230093A 10PK
Kirby Generation V (G5) Motor Unit Assembly

Kirby Generation V (G5) Motor Unit Assembly
Item Part Number
1. Field Coil 120 VT 103989
2. Motor Housing With Tolerance Ring 100196S
3. Screw (Torx) Motor Field 104689A
3. Screw (Torx) Motor Field 104689A
4. Nut Field Screw and Bearing Plate 600589A 10PK
4. Nut Field Screw and Bearing Plate 600589A 10PK
4. Nut Field Screw and Bearing Plate 600589A 10PK
4. Nut Field Screw and Bearing Plate 600589A 10PK
5. Brush Holder With Brush 107110A
5. Brush Holder With Brush 107110A
6. Screw (Torx) Brush Cartridge 107989S 10
6. Screw (Torx) Brush Cartridge 107989S 10
7. Kirby Screw For Power Switch G3-UG 605989A
8. Armature (With Rear Bearing) 120 VT 114789
9. Static Washer 120 VT 601889S 10
10. Finger Spring 314990A
11. Bearing Plate Assembly With Motor Seal 105793S
12. Ring Retainer Bearing Plate 101076A
13. Front Bearing 116073
14. Screw (Torx) Bearing Plate to Motor Housing 600189A 10PK
14. Screw (Torx) Bearing Plate to Motor Housing 600189A 10PK
15. Kirby Fan Assembly Lexan 6 Piece G3/5 119096G
16. Kirby Gear Kit Sprocket/Transmission Gears/Clip 243503S
17. Clip Motor Drive 601689A
18. Clip and Screw Front Motor Mount 233100A
18. Clip and Screw Front Motor Mount 233100A
19. Power Switch 120 VT 110590
20. Brush Lead Assembly Right (120 VT) 602889A 5
21. Brush Lead Assembly Left (120 VT) 602989A 5
22. Motor Seal 600389S 5
23. Rear Bearing 115589
24. Tie Left Brush Lead Hold Down 608089S 10
25. Screw (Torx) Rear Motor Mount 231995S 10
26. Tolerance Ring Bearing Well 612795S
27. Oversized Screw Power Switch 609390S 10
28. Oversized Screw Brush Holder 609490S 10
29. Static Wire Assembly 120 VT 603589A 5
30. Kirby Fan Assembly Lexan 6 Piece G3/5 119096G
31. Spacer Seal Assembly Part No Longer Available
32. Mylar Washer Fan Part No Longer Available
33. Fan Washer Part No Longer Available
34. Fan Pulley Part No Longer Available
Kirby Generation V (G5) Power Drive Assembly

Kirby Generation V (G5) Power Drive Assembly
Item Part Number
1. Power Drive Assembly With Rear Wheels 552399S
2. Kirby Hubcap Rear Wheel Onyx G6 555999A
2. Kirby Hubcap Rear Wheel Onyx G6 555999A
3. Kirby Wheel Rear Black G3-G6 556299
3. Kirby Wheel Rear Black G3-G6 556299
4. Clip Rear Wheel 601689A
4. Clip Rear Wheel 601689A
5. Primary Drive Belt 554189S
6. Foot Pedal 110397
7. Actuating Rod Foot Pedal to Power Switch 612400S
8. Bushing Rear Axle 550889S 10
8. Bushing Rear Axle 550889S 10
9. Right Retainer Axle 555489S 10
10. Left Retainer Axle 555589S
11. Screw (Torx) Axle Retainer 556592A 10PK
12. Spring Rear Axle 555211A
13. Bracket Cam Assembly Neutral Drive Pedal 557689A
14. Screw Neutral Drive Pedal 234097S
15. Bearing Rear Axle 557889S 2
15. Bearing Rear Axle 557889S 2
16. Kirby Pedal Cam For Neutral Drive G6 558499A
17. Clutch Overload Gear Assembly 559892S
18. Kirby Axle Rear Assembly With Gear G3 G4 G5 G6 UG 555211A
19. Rear Axle Assembly With Overload Gear Assembly 555211A
20. Kirby Gear Kit Sprocket/Transmission Gears/Clip 243503S
21. Retainer Axle Ball 561892S 10
22. Ball Rear Axle 561491A 10PK
23. Screw (Torx) Drive System Base Pan 230693A 10PK
23. Screw (Torx) Drive System Base Pan 230693A 10PK
Kirby Generation V (G5) Floor Care Kit with Miracle Waxer

Kirby Generation V (G5) Floor Care Kit with Miracle Waxer
Item Part Number
1. Floor Care Kit Nozzle Assembly 312997S
2. Belt Lifter Body Assembly 159297S
3. Label Belt Lifter 673697S 5
4. Warning Label Floor Care Kit Part No Longer Available
5. Spring Washer 314890S 10
6. Belt Lifter Hook 144291
7. Flat Washer 144681A
8. Bearing Belt Lifter 145481S 10
9. Screw (Torx) Belt Lifter 232596S
10. Baffle Strip 301097S 5
11. Brush Belt 301291S
12. Brush Assembly With Belt Floor Care Kit 313292S
13. Kirby Bare Floor Duster Assembly G6/UG 205906S
14. Miracle Waxer Handle Assembly 480495S
15. Miracle Waxer Roller English 480707S
Kirby Generation V (G5) Carpet Shampoo Assembly

Kirby Generation V (G5) Carpet Shampoo Assembly
Item Part Number
1. CSS Nozzle Assembly Part No Longer Available
2. Belt Lifter Body Assembly 159297S
3. Label Belt Lifter 673697S 5
4. Warning Labels 304297S 5
5. Spring Washer 314890S 10
6. Belt Lifter Hook 144291
7. Flat Washer 144681A
8. Bearing Belt Lifter 145481S 10
9. Screw (Torx) Belt Lifter 232596S
10. Kirby Tray Assembly For Shampooer W/O Shield G4-G6 304799S
11. Tray Belt Baffle 305201S
12. Tray Suds Leveler 305499S
13. Kirby Shield Shampooer Plastic 2HD-LGII 304499
14. Brush Roll Assembly With Axle and Retainer 305702
15. Kirby Tank Assembly For Shampooer G4-G6 306799S
16. Tank Filter Sponge 307389S
17. Kirby Screen For Shampooer Tank G6 316299S
18. Tank Cap 308999
19. Kirby Hose Shampooer Renovator Black G4 G5 G6 308099S
20. Belt 301291S
21. Tank Knob Label Part No Longer Available
22. Kirby Repair Kit For Tank G6 (5pk) 300399S
23. Carpet Fluffer Shield Part No Longer Available
Talk
STAY CONNECTED

Truck
FREE SHIPPING AVAILABLE
All orders over $75 receive free shipping see details >>
