Kirby Generation III (G3)

Kirby Generation III (G3)
Kirby Generation III (G3) Main Body

Kirby Generation III (G3) Main Body
ItemPart Number
1. O Ring Horn Adaptor601996S
2. Rivet Horn Adaptor100689A
3. Exhaust Duct106393
4. Grill Exhaust Duct104189S 5
5. Screw Exhaust Duct605989A
6. Screw Base to Motor233100A
6. Screw Base to Motor233100A
7. Kirby Screw For Rear Motor Mount Torx Type G3-UG231995S 10
8. Screw Fan Case to Base (Top)231595S
9. Screw Fan Case to Base (Bottom)234898S 10
10. Screw Fan Case Front (Flat Head)234998S 10
11. Screw Slide Bracket to Base232495S
11. Screw Slide Bracket to Base232495S
15. Cover Trim Strip Left630989
16. Cover Trim Strip Right630889
17. Scuff Plate With Warning Label111290
18. Screw Scuff Plate233405S
19. Cord Clip & TiePart No Longer Available
20. Screw Cord Clip233405S
21. Screw Cover to Fan Case (Front) 8/32" top232395S
22. Screw Cover to Base (Rear)232495S
23. Kirby Handle Pivot Spring W/Boot Sentria671906G
24. Tilt Knob Handle PivotPart No Longer Available
25. Screw Tilt Knob673289S 25
26. Boot Handle Pivot178601S
27. Screw Pivot Assembly to Slide233897S
28. Kirby Cord 32' Ultimate G192001
29. Cover Cord Set196001
30. Screw Cord Cover232495S
Kirby Generation III (G3) Attachments

Kirby Generation III (G3) Attachments
ItemPart Number
Trigger Spray Gun (Not Shown)251301S
1. Kirby Inflator Tool G6/UG213801
2. Portable Handle Assembly201089S
3. Attachment Grip225189
4. Massage CupPart No Longer Available
5. Intake Guard AssemblyPart No Longer Available
6. Seal Intake Guard224489S 10
7. Kaddy AssemblyPart No Longer Available
8. Spray Gun AssemblyPart No Longer Available
9. Supply Tube Spray Gun250689S
10. Jar Spray Gun251089
11. Crevice Tool Assembly225789S
12. Brush Crevice Tool226157S 5
13. Kirby Upholstery Tool 2HD-LG & G6218099
14. Extension Wand224089
15. Suds O Cap252089S 5
16. Wall Ceiling Brush Assembly210889S
17. Brush Strip Wall Ceiling218190
18. Surface Nozzle Assembly215492S
19. Duster Brush Assembly218489S
20. Duster Brush Ring220189
21. Hose Assembly223689S
22. Molded Hose Only223001
23. Tube Swivel Connector223389
24. Suction Blower Connector Assembly211089S
25. Seal Ring Suction/Blower223881S 10
26. Screw Surface Nozzle PlatePart No Longer Available
27. Kirby Plate Only For Surface Nozzle G3-G5216391
28. Plate Surface Nozzle216391
29. Kirby Plate Only For Surface Nozzle G3-G5216391
30. Spring Surface Nozzle BrushPart No Longer Available
31. Brush Strip Surface Nozzle219190S
37. Suction Relief Upholstery Tool215801
Kirby Generation III (G3) Fan Case Assembly

Kirby Generation III (G3) Fan Case Assembly
ItemPart Number
1. Fan Case Assembly119789S
2. Screw Nozzle Lock1211S
3. Spring Nozzle Lock121297S 10
4. Lever Nozzle Lock121056
5. Bezel Power Switch610001S
6. Nozzle Attaching Shaft121689S
7. Seal Ring122068A
8. Wheel Shaft Assembly (Inside Shaft Length 8 7/16")131606S
9. Label Wheel Shaft Pedal130789S 10
10. Label Height Adjustment632089S 12
11. Screw Micro Adjustment232495S
12. Ratchet Lock Assembly631589A
13. Label Ratchet Lock631889S 10
14. Screw Front Shaft Clamp231294A
14. Screw Front Shaft Clamp231294A
15. Clamp Front Shaft134073A
15. Clamp Front Shaft134073A
16. Hubcap Front Wheel131889A
16. Hubcap Front Wheel131889A
17. Front Wheel131901
17. Front Wheel131901
18. Screw Front Wheel231695A
18. Screw Front Wheel231695A
19. Spring Ratchet Lock1331A
20. Volute Deflector125489
Kirby Generation III (G3) Handle Assembly

Kirby Generation III (G3) Handle Assembly
ItemPart Number
Paper Bag (3 pack) (Not Shown)197289SW
Paper Bag (9 pack) (Not Shown)197389AW
1. Handle Fork Assembly175090G
2. Latch Plate672189
3. Screw Latch Plate233797S
4. Label Handle Fork174390S 5
5. Lower Label Handle Fork673589S 10
7. Kirby Handle Fork Back Cover Gray G3673789S
8. Retainer Ring Strain Relief675189S
9. Kirby Screw Handle Fork Back 1CR-UG174996S
10. Cord Hook Swivel173889S
11. Screw Cord Hook SwivelPart No Longer Available
12. Spring Cord Hook Swivel174167A
13. Handle Grip Assembly Light Gray675791
14. Kirby Mini Emtor Assembly G6188999
15. Fill Tube190384S CASE 72
16. Top Adapter Fill Tube190484
17. Tube Tie191182S
20. Kirby Strap To Clamp Bag to Emtor G3 Ultimate196501S
21. Bag Assembly With Bag Top Cover Assembly190091S
22. Rear Cover Assembly673789S
23. Bag Release Button Handle Grip672089S 5
24. Bag Hanger Bar AssemblyPart No Longer Available
25. Star Washer Bag HangerPart No Longer Available
26. Kirby Bag Cloth W/Top Cover G3 Gray190091S
27. Spring Bag TopPart No Longer Available
28. Hook Bag TopPart No Longer Available
29. Bag Top Cover191889
Kirby Generation III (G3) Headlight Cap / Slide Bracket Assembly

Kirby Generation III (G3) Headlight Cap / Slide Bracket Assembly
ItemPart Number
1. Headlight Cap Less Trim160089
2. Lens Headlight Cap108589
3. Light Bulb109292S
4. Headlight Frame Bracket161790
7. Screw Frame Bracket to Cap162689A
8. Screw Headlight Pivot to Slide Bracket232495S
9. Headlight Pivot Casting161389
10. Bushing Headlight Pivot161689S 5
11. Plate Headlight Pivot162889S 5
12. Screw Plate to Headlight Pivot102168S 25
13. Slide Bracket Casting894003S
14. Wedge Slide Adjustment179489S
15. Guide Block Slide Bracket178797S
15. Guide Block Slide Bracket178797S
16. Screw Guide and Wedge to Slide Bracket234397S 10
16. Screw Guide and Wedge to Slide Bracket234397S 10
16. Screw Guide and Wedge to Slide Bracket234397S 10
17. Roller Bearing Assembly178989S 10
18. Slide Slide Bracket Assembly676595S
19. Cable Tie Lead Wires608089S 10
20. Headlight Harness Assembly603889S
Kirby Generation III (G3) Motor Unit Assembly

Kirby Generation III (G3) Motor Unit Assembly
ItemPart Number
1. Field Coil103989
2. Motor Housing100196S
3. Screw Motor Field104689A
4. Nut Field Screw600589A 10PK
4. Nut Field Screw600589A 10PK
6. Brush Holder With Brush107110A
6. Brush Holder With Brush107110A
7. Screw Brush Cartridge107989S 10
7. Screw Brush Cartridge107989S 10
8. Screw Power Switch to Motor Housing605989A
9. Armature With Rear Bearing114789
10. Static Washer601889S 10
11. Finger Spring314990A
12. Bearing Plate Assembly105793S
13. Ring Retainer Bearing Plate101076A
14. Front Bearing116073
15. Screw Bearing Plate to Motor Housing600189A 10PK
15. Screw Bearing Plate to Motor Housing600189A 10PK
16. Fan Assembly Lexan119096G
17. Kirby Gear Kit Sprocket/Transmission Gears/Clip243503S
18. Clip Motor Drive601689A
19. Clip Motor Housing233100A
19. Clip Motor Housing233100A
20. Power Switch110590
21. Brush Lead Assembly Right602889A 5
22. Brush Lead Assembly Left602989A 5
23. Motor Seal600389S 5
24. Static Wire Assembly603589A 5
Kirby Generation III (G3) Floor Nozzle Assembly

Kirby Generation III (G3) Floor Nozzle Assembly
ItemPart Number
1. Nozzle Assembly Less Brush and Belt141690S
2. Kirby Body For Belt Lifter W/Label Plastic Gray G3159289S
3. Label Tech Drive Blue673689S 10
4. Screw Belt Lifter232596S
5. Belt Lifter Body With Arrow Labels159289S
6. Flat Washer Belt Lifter144681A
7. Spring Washer Belt Lifter314890S 10
8. Kirby Label For Belt Lifter UG (5pk)146606S
9. Kirby Label For Brush adjusetment G5/G6 5 Pack149801S
10. Bearing Belt Lifter Blue145481S 10
11. Hook Belt Lifter Blue144291
12. Latch Assembly640689A 2
13. Rivet Latch Assembly141381S 10
14. BPI AssemblyPart No Longer Available
15. Screw BPI Assembly605989A
16. Nozzle Bumper Less Trim Strip140489
17. Rug Plate152604
18. Brush Roll Assembly Ball Bearing156294G
19. Brush End Cap SmallPart No Longer Available
20. Brush End Cap LargePart No Longer Available
21. Belt Brush Roll301289S
Kirby Generation III (G3) Power Drive Assembly

Kirby Generation III (G3) Power Drive Assembly
ItemPart Number
1. Power Drive Assembly With Rear Wheels552389S
2. Kirby Hubcap For Rear Wheel Ultimate Diamond555901A
3. Rear Wheel556299
4. Clip Rear Wheel601689A
5. Primary Drive Belt554189S
6. Foot Pedal110389
7. Actuating Rod Foot Pedal to Power Switch612400S
8. Bushing Rear Axle550889S 10
9. Right Retainer Axle555489S 10
10. Left Retainer Axle555589S
11. Screw Axle Retainer556592A 10PK
12. Spring Rear Axle555211A
13. Bracket Cam Assembly Neutral Pedal557689A
14. Screw Neutral Pedal234097S
15. Bearing Rear Axle557889S 2
16. Neutral Pedal Cam Assembly558491A
17. Clutch Overload Gear Assembly559892S
18. Rear Axle Assembly With Gears555211A
18. Kirby Axle Rear Assembly With Gear G3 G4 G5 G6 UG555211A
Kirby Generation III (G3) Carpet Shampoo System

Kirby Generation III (G3) Carpet Shampoo System
ItemPart Number
1. Carpet Shampoo Nozzle Assembly303189S
2. Belt Lifter Body With Arrow Labels159289S
3. Label Tech Drive673689S 10
4. Kirby Body For Belt Lifter W/Label Plastic Gray G3159289S
5. Kirby BPI Sensor Assembly G4-UG640303
6. Label Arrow GreenPart No Longer Available
7. Label WarningPart No Longer Available
8. Spring Washer314890S 10
9. Belt Lifter Hook144291
10. Flat Washer144681A
11. Bearing Belt Lifter145481S 10
12. Screw Belt LifterPart No Longer Available
14. Kirby Tray Assembly For Shampooer Ultimate304701S
15. Belt Baffle Strip305201S
16. Suds Leveler Strip305401S
17. Shield304401
18. Brush Roll Assembly With Axle and Retain305702
19. Tank Assembly306701S
20. Filter Sponge Tank307389S
21. Kirby Screen For Shampooer Tank G6316299S
22. Cap Tank308901
23. Hose Assembly308001S
24. Belt301289S
26. Carpet Fluffer ShieldPart No Longer Available
